Key Features Model: LS109P Ports: 9× 10/100 Mbps RJ45 Ports PoE Ports: 8× 10/100 Mbps 802.3af/at PoE+ Ports) Switching Capacity: 1.8 Gbps, Forwarding Rate: 1.3392 Mpps Up to 250 m PoE Transmission, 63 W PoE Budget Read more
The TP-Link LS109P 9-Port 10/100Mbps PoE Switch includes 8-Port PoE+, which has a 63W PoE budget and can power up to eight devices such as IP cameras, access points, and IP phones via its 802.3af/at-compliant PoE+ ports, each of which can output up to 30W. Extend Mode increases PoE transmission distances to 250 meters, making it ideal for deploying devices in large areas. Its PoE Auto Recovery feature ensures consistent operation by rebooting unresponsive PoE-powered devices. For added security, the TP-Link LS109P 9-Port 10/100Mbps PoE Switch's Isolation Mode feature divides client traffic with a single click, reducing the risk of data snooping and broadcast storms. The LS109P's plug-and-play functionality allows for easy installation and eliminates the need for configuration. Its fanless design ensures quiet operation, making it ideal for noise-sensitive environments like offices or homes. It has a durable metal casing and supports both desktop and wall-mounted configurations, providing installation flexibility. The TP-Link LS109P 9-Port 10/100Mbps PoE Switch has nine 10/100 Mbps RJ45 ports, eight of which are PoE+, and supports AUTO Negotiation and MDI/MDIX for seamless connectivity. Designed for performance, the switch has a switching capacity of 1.8 Gbps and a packet forwarding rate of 1.3392 Mpps. Its 2K MAC address table enables efficient network management, while the 1.5 KB jumbo frame improves data transfer performance. Advanced features include IEEE 802.3x flow control, environmentally friendly technology, and compatibility with IEEE 802.3af/at devices. The TP-Link LS109P 9-Port 10/100Mbps PoE Switch with 8-Port PoE+ is powered by an external adapter that delivers 53.5VDC/1.31A.
| Specifications | Descriptions |
|---|---|
| Main Feature | |
| Type | Desktop Switch |
| Advanced Functions | Extend Mode Button (Ports 1–4/1–8, Up to 250 m PoE power supply and data transmission) Isolation Mode Button (Ports 1–8) PoE Auto Recovery Button (Ports 1–8) Compatible With IEEE 802.3af/at Compliant PDs Mac Address Auto-Learning and Auto-Aging IEEE 802.3x Flow Control Green Technology |
| Transmission Method | Store and Forward |
| Data Transmission Rate | Switching Capacity: 1.8 Gbps Packet Forwarding Rate: 1.3392 Mpps |
| MAC Address Table | 2K |
| Environment | Operating Temperature: 0–40 ℃ (32–104 ℉) Storage Temperature: -40–70 ℃ (-40–158 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing |
| Hardware Features | |
| Interface | 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ Ports) |
| LED | Power Link/Act PoE Status PoE MAX |
| Power Supply | Max Power Consumption: 3.67 W (220 V/50 Hz no PD connected) 73.24 W (220 V/50 Hz with 63 W PD connected) |
| Dimensions (L x W x H) | 6.7×3.9×1.1 in (171×98×27 mm) |
| Manufacture Warranty | |
| Warranty | 01 Year Warranty |
