NetPro 1x8 PLC splitter is a device that uses a Planar Lightwave Circuit to split a single optical fiber input into eight identical optical outputs. It is a passive component used in telecommunications to distribute signals from one source to multiple destinations, such as in EPON/GPON and FTTX networks. Key features include its ability to operate across a wide wavelength range (1260-1650 nm), low insertion and polarization dependent loss, and high reliability. Read more
| Specifications | Descriptions |
|---|---|
| Optical performance | Operating Wavelength: 1260 nm – 1650 nm Insertion Loss: \(\le 10.5\) dB to \(10.8\) dB (varies by manufacturer and specific model) Return Loss: \(\ge 55\) dB Uniformity: \(\le 1.0\) dB Polarization Dependent Loss (PDL): \(\le 0.3\) dB Directivity: \(\ge 55\) dB |
| Environmental and physical | Operating Temperature: \(-40^{\circ }C\) to \(+85^{\circ }C\) (or \(-20^{\circ }C\) to \(+70^{\circ }C\)) Storage Temperature: \(-40^{\circ }C\) to \(+85^{\circ }C\) Connector Type: Typically SC/APC Fiber Type: Often G.657A1 single-mode fibe |
| Approvals and certifications | Telcordia GR-1221 and GR-1209: Meets industry standards for reliability ISO-9001 and TUV Certified: Indicates a certified manufacturing process RoHS Compliant: Restricts the use of hazardous materials |
